SUNIX 台湾三泰 UTS1009B USB转1串口RS-232转换器

产品价格：: ¥ 120.00

立即咨询：: 在线咨询 QQ咨询

品牌：: 三泰

型号：: UTS1009B-USB1RS-232

成色：: 全新 | 保修365天

此商品已下架()

诚信认证：

在线客服

产品分类

易卖工控网（www.ymgk.com）提供”SUNIX 台湾三泰 UTS1009B USB转1串口RS-232转换器”，产品详情：品牌/厂家：三泰、型号：UTS1009B-USB1RS-232、成色：全新、货期：期货 7天内发货、保修：365天，更多产品详情就上易卖工控网。

台湾三泰串口卡

UTS1009B

USB转1口RS - 232串口转换器

Introduction

No longer would the usage of a serial or parallel device be restricted by the availability of the connectable ports on the desktop, laptop or work station system. With SUNIX ComHub USB Adapter, users now have the ability to convert the connection of their serial and parallel peripherals into USB (Universal Serial Bus) compatible. The adapter is compatible with both USB 2.0 and 1.1 specifications. The USB Full Speed connection offers data transfer rate up to 12Mbps. SUNIX ComHub provides serial ports with transfer speed up to 115.2Kbps.

SUNIX ComHub, USB to I/O Adapter utilized the high quality Prolific chipset, not only is the ComHub has passed the WHQL certification, it is also the most compatible and the most reliable. ComHub series come with the choice of 1/2/4 ports in RS-232 or Printer (LPT) for connection with devices such as barcode scanner, POS device, PDA, printer, and other mobile devices. SUNIX offers the most complete line of USB to I/O Adapter for all your connection needs.

Features

Expands 1 RS-232 ports on system via USB connection.
Supports Universal Serial Bus Plug-n-Play and Hot-Swapping feature.
No IRQ, DMA, I/O address resource required.
Supports USB1.1 full speed 12Mbps, and it is USB2.0 compatible.
Each serial port provides transmission rate up to 115.2Kbps.
Built-in ±15KV ESD protection for all serial signals.
Plug-n-Play, I/O address and IRQ assigned by BIOS.
Certified by CE, FCC, RoHS, and Microsoft WQHL approval.
Support Microsoft Windows, Linux, Mac and DOS.

Specifications

Description

Product Description

1 ports USB to RS-232 Serial Adapter

Serial Communication

Interface	RS-232
Controller	Prolific 2303Hx 16C550 UART Compatible
Bus Interface	Universal Serial Bus (USB) 2.0 / 1.1
No. of Port	1-port
IRQ & IO	Assigned by System
FIFO	16 byte (Hardware)
Signal	TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND, RI
Baud rate	50 bps to 115.2 Kbps
Data bit	5,6,7,8
Stop bit	1,1.5,2
Parity	None, Even, Odd, Space, Mark
Flow Control	RTS/CTS (Hardware) , XON/XOFF(Software)
Protection	±15KV ESD protection for each signal Human Body Model (HBM)
Board connector	DB9 Male

Driver Support

Microsoft	98/ME/2000/XP/2003/Vista/2008/7 (32/64 bit)/CE5.0/XP Embedded
Linux	Linux 2.4.x/2.6.x
MAC	MAC 10.1, 10.4, 10.5 (Leopard)

Regulatory Approvals

Hardware	EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, FCC Part 15 Class B, RoHS
Software	Microsoft WHQL Window XP

Environment

Operating Temperature	0 to 60 °C ( 32 to 140 °F )
Operating Humidity	5% to 95% RH
Storage Temperature	-20 to 85 °C ( -4 to 185 °F )

Power

Input	USB Bus-power
Consumption	< 0.8W = 5V x 150mA

Mechanical

Dimension	75 (W) x 40 (D) x 22 (H) mm
Cable Length	1500mm (5ft)
Case	ABS
Weight	114 ± 5 g
