IC641CTL904模块备件

易卖工控网（www.ymgk.com）提供”IC641CTL904模块备件”，产品详情：品牌/厂家：、型号：IC641CTL904、成色：全新、货期：现货 1天内发货、保修：180天，更多产品详情就上易卖工控网。

IC752WFB203

控制器在77°F（25°C）下接受1097欧姆PTC：
•50021579-001–标准传感器（包括所有传感器）
型号（NEMA 4X型号除外）
•T775-SENS-STRAP–带接线盒的带式传感器
•T775-SENS-WR–防水，带5英尺引线
（包括NEMA 4X型号）
•T775-SENS-WT–6英尺引线防水
•T775-SENS-OAT–室外空气温度传感器
•C7031B2005–带接线盒的6英寸管道安装
•C7031D2003–带接线的5英寸浸入式传感器
盒子（使用浸没井；P/N 50001774-001）
•C7031J2009–12英尺管道平均传感器，带
接线盒
•C7046D1008–带安装法兰的8英寸管道探头
•C7100D1001–12英寸快速响应，管道平均
带法兰的传感器
•C7130B1009–室内安装传感器
配件
•107324A–灯座，管道插入
•107408–导热化合物，4盎司
•50001774-001–浸没井，不锈钢304，
1/2英寸。穿线。
产品变更
以下是对T775A/B/M型号的更改，从
系列3（2009年3月）。系列3可通过以下方式识别：
在设备标签上的零件号后横向3。
1.调制上限和下限现在都在
加热或冷却模式。
2.添加小值。
3.添加同步。
4.压差和节流范围增加到300°F。
5.添加到DI的设定值和启用选项
选项。
6.添加到MOD1和MOD2的隐藏选项（隐藏
在主屏幕上显示）。
控制器尺寸
图1.T775A/B/M尺寸单位为英寸（mm）。
a参见表62-0265-T775的温度传感器
2000系列独立控制器
4 13/32 (112.1) 1/2 (12.4)
3 31/32 (101)
7 23/32
(196)
8 5/32
(207.1)
2 15/16 (74)
7/8 (22.5)
1 (25.5)
4 1/16 (103.4)
4 1/16 (103.4)
1/64 (3.8)
2 11/16 (68.1)
7/8 (22.5)
2 13/16 (71.8)
7/8 (22.5)
1 (25.5)
7/8 (22.5)
M24279
顶
底部
左右
前视图
T775A/B/M系列2000电子独立控制器
3 62-0254—13
在安装之前
检查35页上的“规范”，然后
安装控制器。
安装本产品时
1.仔细阅读这些说明。不遵守
它们可能会损坏产品或导致故障
危险状况。
2.检查说明书和图纸上给出的额定值
确保产品适合您的客户
应用
3.安装人员必须是经过培训、经验丰富的服务人员
技术员
4.安装完成后，检查产品
操作如本说明书所述。
安装和设置
通常需要执行以下安装步骤：
按下列顺序执行：
1.安装-见下面的“安装”。
2.接线-参见本页的“接线”。
3.结账-见11页。
4.编程-见14页。
5.调度（可选）-见30页。
其他主题包括：
•温度传感器校准从11页开始。
•界面概述从12页开始。
•设置（级选项）从17页开始。
•摘要菜单从34页开始。
•故障排除从34页开始。
安装
本节介绍了发动机的安装程序
控制器和温度传感器。
控制器安装
重要的
避免安装在有酸雾或有毒气体的区域
其他恶化的蒸汽会腐蚀金属
控制器电路板的部分或区域中
如果逸出气体或其他爆炸性蒸汽
存在。
重要的
控制器必须安装在以下位置：
允许布线、维修和维护的间隙
移动
使用螺丝刀仅撬出您需要的敲孔
它将使用。
如果安装在DIN导轨上，请务必拆下顶出件
在安装之前。参见5页的“控制器接线”，以及
6页的图7显示了推荐的敲除用法，以及
位置。如果您不使用开放式淘汰赛，请确保：
以覆盖它。
将控制器安装在任何方便的内部位置
使用设置在外壳背面的四个安装孔
使用#6或358螺钉的外壳（未提供螺钉
并且必须单独获得）。使用控制器
2页图1中的尺寸作为参考。
控制器可以以任何方向安装。
然而在图1中所示的方向上安装
2页允许正确查看LCD显示和使用
在键盘上。
NEMA 4外壳安装
对于带有NEMA 4外壳的型号，确保：
在脱模处使用防水电线/导管配件
适用于所有接线附件。有关详细信息，请参阅6页的图7
淘汰位置。
重要的
对于NEMA 4外壳，确保覆盖和
密封所有未使用的开放式淘汰赛。
温度传感器安装
和位置
温度传感器的位置可能达1000英尺
（304米）从T775A/B/m控制器。参见表3
关于校准指南，请参见11页。
传感器可以安装在墙壁或面板上
传感空间温度，绑在管道上或插入
在用于热水或冷水的浸没井（见图2）中
或者用胶带固定到用于管道的标准盖或灯泡座上
空气感应。为了防止湿气或冷凝进入
通过导线孔安装传感器，安装传感器
引线从传感器的底部引出。
笔记：
1.所包含的传感器未被拆卸

IC752WFB203

IC752WFB203
