FM-720-507579模块备件

Electronic Development Corp-507939

Overview From 5 amp miniature to 2650 amp large-frames, Rockwell Automation® offers IEC contactors that are flexible, modular and easy to select and apply, with coordinating accessories, SCCR documentation and a PLC-compatible universal electronic AC/DC coil that reduces energy consumption. When paired with our Bulletin 140G/140MG circuit breakers, customers can obtain documented short circuit coordinated ratings (SCCR) with the Rockwell Automation® online global SCCR selection tool. This enables users to select the specific combinations of Allen-Bradley components they are applying—circuit breakers, contactors, overload relays—and obtain a test summary letter documenting the compliance of their specific products with to IEC and UL standards. This documentation is based on coordinated testing conducted in Rockwell Automation accredited test facilities and witnessed by Underwriters Laboratories. Features and Benefits: • • • • • • • Direct-on-line and reversing contactors Built-in surge suppression with electronic coils AC and DC coil control Complete range of accessories within each contactor family Compatible with our Bulletin 193 Overload Relays and Bulletin 140M Motor Protection Circuit Breakers Meet IEC, UL, and CSA standards requirements RoHS compliant Supports IE3 Motor Switching Safety contactors Environmentally friendly, versatile and flexible, our IEC contactors provide modular solutions up to 2650A. • • Large IEC Contactors 100-E / 104-E Compact IEC Contactors 100-C / 104-C The Bulletin 100-C offers a space-saving design in a high performance contactor. The low power consumption contactor is designed to control motors and other loads. New designs reduce width and weight saving panel space. The new universal electronic AC/DC coil for these sizes makes selection much easier, with far fewer variations required to cover a wide range of applications. Plus the low (10 mA, 24V DC) switching energy enables direct connection to PLCs without interposing relays. The universal coil also offers significant energy savings, especially in common isolation, bypass and alternate energy applications. • 116...2650A • Electronic wide-range, AC/DC coils coils - Optional integrated PLC interface - Low Power hold-in current - Integrated surge suppression 140MG Circuit breaker - motor protection 100-E IEC Contactor 24V DC coil reduces dropout time to 18-23ms Certifications • CE Marked • cULus Listed (File No. E3125; Guide NLDX, NLDX7) • CCC Certifications • CE Marked c-UL-us Listed (File No. E41850/E196120, Guide NLDX, NLDX7) CCC EAC RCM • • 104-C Reversing IEC Contactor • 9... 97A • Reversible coil terminals • Available 4-pole contactors (9...23A, 40A & 90A) • Front and side mounting of auxiliary contacts • 35mm DIN Rail mount or panel mount • Spring-clamp terminals available (9...16A) • • IEC Contactors 100-D / 104-D The Bulletin 100-K miniature contactors are designed for commercial and light industrial applications where panel space is at a premium. These miniature devices, while 45 mm wide, are shallower and have less panel depth requirements than standard IEC contactors. • 5...12A • Same dimensions AC and DC • Front mount auxiliary contacts available • Optional 2- or 4-pole adder decks provide a variety of auxiliary contact configurations • Spring-clamp terminals avilable: 5A & 9A • Available 4-pole contactors in all sizes Miniature IEC Contactors 100-K / 104-K Safety Contactors 100S-C / 104S-C, 100S-E The Bulletin 100S safety contactors provide mechanically linked positively guided or mirror contact performance, required in feedback circuits of modern safety applications. • SUVA third party certification • AC and DC operating coils • Gold plated, bifurcated auxiliary contacts Certifications • CCC • CE Marked • cULus Listed (File No. E 41850, Guide NLDX, NLDX7) Certifications • CCC • CE Marked • cULus Listed (File No. E 41850, Guide NLDX, NLDX7) 100S-E • cULus Listed (File No. E3125, Guide NLDX, NLDX7) 100S-C • SUVA Certified 100-K IEC Contactor Surge suppressor Auxiliary contact Accessories Each IEC Contactor family features a range of accessories that are common within that family. Auxiliary contact block Reversing wiring kit Mechanical interlock Connecting module Electronic Timer (100-C) Surge suppressor modules Auxiliary contacts Terminal lugs Terminal shrouds Connection bars for 140G circuit breakers
